Low Profile Pumping Unit
LOWJACK
LP Low profile Pumping Units is a new kind of non-beam energy-saving pumping units, it’s
a power equipment on the ground used in sucker rod oil
extraction.
The
products conform to API Spec.11E “Specification for Pumping
Units” and other relative API standards, acquired the
authorization to use Official API Monogram.
Technical Performances
1、Use roller and belt to form flexible drive, improve
impulsive load, prolong service life of gear reducer.
2、Abnormally design of crank arm make it balanced completely.
3、Gear reducer is involute herring-bone gearing, work smoothly
and reliably.
4、Small cubage, light weight, the complete machine can be
folded totally, it’s convenient for installation and
transportation.
Main Technical Parameter
|
No |
Type |
Polished Rod Capacity
（lb） |
Stroke Length
（in） |
Rated Torque
（in.lb） |
|
1 |
LP-320-256-120 |
25,600 |
120、102、85 |
320,000 |
|
2 |
LP-320-256-100 |
25,600 |
100、85、70 |
320,000 |
|
3 |
LP-320-246-86 |
24,600 |
86、71、56 |
320,000 |
|
4 |
LP-228-256-100 |
25,600 |
86、71、56 |
320,000 |
|
5 |
LP-228-213-86 |
21,300 |
86、71、56 |
228,000 |
|
6 |
LP-228-246-86 |
24,600 |
86、71、56 |
228,000 |
|
7 |
LP-228-246-74 |
24,600 |
74、64、53 |
228,000 |
|
8 |
LP-160-173-86 |
17,300 |
86、74、62 |
160,000 |
|
9 |
LP-160-200-74 |
20,000 |
74、64、53 |
160,000 |
|
10 |
LP-160-173-74 |
17,300 |
74、64、53 |
160,000 |
|
11 |
LP-114-173-64 |
17,300 |
64、54、44 |
114,000 |
|
12 |
LP-114-143-54 |
14,300 |
54、44、34 |
114,000 |
|
13 |
LP-114-109-54 |
10,900 |
54、43、32 |
114,000 |
|
13 |
LP-80-133-54 |
13，300 |
54、43、32 |
80,000 |
|
